Industrial Dye-Sublimation Printer — 2000 mm, Kyocera Heads

S8000 (Kyocera)

The 2000 mm S8000 frame with Kyocera EX600 heads, in four, eight or twelve-head configurations.

Print width: 2000 mm
Max productivity: 620 m²/h
Ink configuration: Up to 10 colours from a 10 L bottle supply

Connect with us for a quotation tailored to your production.

Request a Quote WhatsApp [email protected]

Introduction

The Kyocera build of the S8000 puts Kyocera EX600 heads on the same 2000 mm industrial frame, in four, eight or twelve-head configurations so the machine can be specified to the volume a shop actually runs. It takes the same ten-colour sublimation ink set from 10 L bottles under automatic negative-pressure feed, the same honeycomb suction deck and tower support, and the same THK magnetic-levitation drive. Three-phase power, infrared hot-air circulation drying and a tension-roller transfer system with a Φ1000 mm unwinder make it a machine for continuous heat-transfer production.

Core advantages

Scales to the volume you run Four, eight or twelve Kyocera EX600 heads on the same frame — 310 m²/h at four heads, 620 m²/h at eight or twelve.
Ten-colour capability CMYK plus light cyan, light magenta, light black, grey, fluorescent red and fluorescent yellow.
Honeycomb suction deck Honeycomb uniform suction printing platform over a tower support structure, holding media flat so it prints without creasing.
Magnetic-levitation drive THK soundproof double guides with magnetic motor and magnetic grid system.
Automatic ink feed 10 L bottles with automatic ink feeding and automatic negative pressure control.
Three-tier head protection Three tier print head protection with an automatic cleaning and moisturising integrated component.
Tension roller transfer Rubber press roller φ160 mm/220 mm, unwinder to Φ1000 mm, rewinder to Φ450 mm.
Double heating drying Infrared hot-air circulation with double heating for fast, even drying.

Technical specifications

Print heads and speed

Speed figures are m²/h.

Print head	Kyocera EX600
Number of print heads	4 \| 8-(4C) \| 12-(6C)
Maximum printing speed	310 m²/h \| 620 m²/h \| 620 m²/h

Print media

Print width	2000mm
Media type	Sublimation paper
Media thickness	0.02-0.5mm

Ink

Ink type	Sublimation ink
Colours	cyan, magenta, yellow, black, light cyan, light magenta, light black, grey, fluorescent red, fluorescent yellow
Ink tank	10L/bottle
Ink feeding	automatic ink feeding and automatic negative pressure control

Software

Production software	optional software includes TexPrint, NeoStampa
File format	TIFF/JPG/EPS/PDF, Color mode support RGB and CMYK

Function configuration

Platform supporting structure	tower support structure
Printing deck	honeycomb uniform suction printing platform 3.0
Magnetic levitation drive system	THK soundproof double guides, magnetic motor, magnetic grid system
Printhead protection system	Three-tier protection
Cleaning and moisturising	automatic cleaning and moisturising integrated component
Tension roller transfer system	press roller: Rubber roller φ160mm/220mm(cylinder) / unload: MAX up to Φ1000mm / rewinder: MAX up to Φ450mm

Working environment

Drying	Infrared hot air circulation double heating
Electrical	380VAC±5%, Three phase five wire/220VC, 50/60HZ
Power	printer 6KW, dryer 10KW
Compressed air	0.5~0.7Mpa, 0.15m2/hr (Dry, oil-free and steam-free)
Temperature/humidity	recommended temperature 15-30 °C Humidity 50%-80% (No condensation)
